Sprague 242E225 8.2K Ohm 2.4W Wirewound Resistor NSN 5905-00-581-1644 NOS
New old stock Sprague fixed wirewound inductive resistor from military/government surplus inventory. This is an individually packaged Mil-Spec component with an 8.2 kΩ resistance rating and 2.4 watt free-air power rating. Components like this are increasingly difficult to find in original surplus stock and can be useful for military electronics maintenance, restoration, test equipment, industrial repair, and applications requiring the exact part number, NSN, or military specification. Photos show the actual type of component and packaging being offered.
TECHNICAL INFORMATION
Electrical Resistance: 8.200 KILOHMS
Resistance Tolerance: -5.000% to 5.000%
Power Rating: 2.400 Watts, Free Air
Body Diameter: 0.203 Inches Nominal
Body Length: 0.531 Inches Nominal
Construction: Fixed Wire Wound, Inductive
Enclosure: Encapsulated
Terminal Type: Wire Lead
Style: Axial Terminal Each End
TEMPERATURE RATINGS
Temperature Coefficient: -60.0 to 60.0 ppm/°C
Temperature Coefficient Range: -55.0°C to 340.0°C
Ambient Temperature at Zero Rated Power: 340.0°C
Ambient Temperature at Full Rated Power: 40.0°C
MILITARY / GOVERNMENT DATA
NSN: 5905-00-581-1644
Manufacturer: Sprague
Part Number: 242E225
Reliability Indicator: Not Established
Specification / Standard: 81349-MIL-R-10509/3 Government Specification
FIIG: A001A0
INC: 37403
Item Classification: RESISTOR, FIXED, WIRE WOUND, INDUCTIVE
FIIG / INC DESCRIPTION
A fixed resistor whose ohmic value cannot be adjusted or varied. The resistance element consists of high-resistance wire or ribbon wound on an insulated form or constructed to be self-supporting. This classification specifically identifies a wirewound resistor having inherent self-inductance.
CONDITION
New old stock military/government surplus. Individually packaged to military packaging standards. Packaging may show age from long-term storage. Please compare the NSN, manufacturer part number, specifications, and photographs with your requirements before purchase.
Sold by Sumspace, operated by Southern Utah Makerspace Inc., a 501(c)(3) nonprofit in St. George, Utah. We are working through a large inventory of military, industrial, and government surplus components and putting useful material back into productive use instead of letting it go to waste. Check Sumspace.org for additional surplus electronics, industrial parts, and hard-to-find components as they are identified and listed.
New old stock military-spec fixed film resistor network, part number M8340108K2200GG, from government surplus inventory. This encapsulated single-inline network contains four identical 220-ohm resistors with eight pin terminals and a total power dissipation rating of 0.480 watt. It is an individually packaged Mil-Spec component suitable for military electronics maintenance, restoration, test equipment, industrial repair, and applications requiring the exact part number, NSN, or MIL-R-83401 specification. Photos show the actual type of component and packaging being offered.
TECHNICAL INFORMATION
Electrical Resistance: 220.000 OHMS Each Resistor
Resistance Tolerance: -2.000% to 2.000% Each Resistor
Identical Value Resistor Quantity: 4
Power Dissipation: 0.480 Watts Total Network
Schematic Diagram: Isolated Array
Enclosure Method: Encapsulated
Terminal Quantity: 8
Terminal Type: Pin
Terminal Length: 0.125 Inches Minimum to 0.150 Inches Maximum
Body Length: 0.768 Inches Minimum to 0.798 Inches Maximum
Body Width: 0.050 Inches Minimum to 0.103 Inches Maximum
Body Height: 0.177 Inches Minimum to 0.197 Inches Maximum
Style: Single Inline
Cubic Measure: 0.016 Cubic Inches
Unpackaged Unit Weight: 1.5 Grams
TEMPERATURE RATINGS
Temperature Coefficient: -100.0 to 100.0 ppm/°C
Temperature Coefficient Range: -55.0°C to 125.0°C
Ambient Temperature at Full Rated Power: 70.0°C
Ambient Temperature at Zero Percent Rated Power: 125.0°C
MILITARY / GOVERNMENT DATA
NSN: 5905-01-283-4390
Part Number: M8340108K2200GG
Reliability Indicator: Not Established
End Item Identification: 6930K4309806
Test Data Document: 81349-MIL-R-83401 Specification
Specification / Standard: 81349-MIL-R-83401/8 Government Specification
FIIG: A001A0
INC: 32068
Item Classification: RESISTOR NETWORK, FIXED, FILM
FIIG / INC DESCRIPTION
An arrangement of multiple fixed resistive elements or discrete resistors permanently encased, encapsulated, or potted together to form an inseparable unit. The resistive elements consist of a thin layer of conductive material deposited on or fused to an insulating base. The elements may be electrically connected and arranged in a circuit configuration.
CONDITION
New old stock military/government surplus. Individually packaged to military packaging standards. Packaging may show age from long-term storage. Please compare the NSN, part number, specifications, and photographs with your requirements before purchase.
Sold by Sumspace, operated by Southern Utah Makerspace Inc., a 501(c)(3) nonprofit in St. George, Utah. We are working through a large inventory of military, industrial, and government surplus components and putting useful material back into productive use instead of letting it go to waste. Check Sumspace.org for additional surplus electronics, industrial parts, and hard-to-find components as they are identified and listed.
Bourns 3057L-1-102M wirewound variable resistor, rated at 1,000 ohms (1KΩ) and 1 watt. NSN 5905-00-787-8915. This military surplus electronic component comes in its original packaging dated March 1988 and is suitable for equipment maintenance, electronics restoration, and replacement applications requiring this specific part number.
PRODUCT DETAILS
Manufacturer: Bourns Inc.
Manufacturer Part Number: 3057L-1-102M
NSN: 5905-00-787-8915
FSCM/CAGE: 32997
FSC: 5905 – Resistors
Type: Wirewound Variable Resistor / Trimmer Potentiometer
Resistance: 1,000 Ohms (1KΩ)
Power Rating: 1 Watt
Tolerance: ±5%
Adjustment: 22-Turn, Side Adjustment
Quantity: 1 Each 10.3g
Contract Number: DLA900-88-M-J976
Packaging Date: 03/88
CONDITION
New old stock (NOS) in original military surplus packaging dated March 1988. Packaging shows age and handling marks consistent with long-term storage. Component has not been electrically tested. Photos show the actual package.
ABOUT SUMSPACE
Sold by Southern Utah Makerspace (Sumspace), a nonprofit organization supporting material reuse, practical manufacturing, and resource conservation.
Explore additional military surplus, industrial components, and electronic parts at Sumspace.org.
